TV7511 466572-0001 8927026 MTU Detroit Diesel Highway Truck 6V92TAB Engine turbocharger

Product Detail

TV7511 Turbo 466572-0001 R8927026 Turbocharger for Detroit Diesel Truck 6V92TAB 6V92 Engine

Product Details

Part Number	466572-5001S
Previous Version	466572-0001, 466572-9001, 466572-1
OE number	08927026, R8927026, 8927026, R5141676
Superseded by part	R5103840
Description	Truck 6V92, Highway Truck
CHRA	442032-0010 (442032-5010S, 23501286) $996.32 NEW IN STOCK
Turbo Model	TV7511
RPM	2100
Displacement	9.0L, 9000 ccm, V6 Cylinders
KW	350 HP
Fuel	Diesel
S/N	0HD200
Bearing Housing	442028-0001 (8925742, 08925742) $211.73 NEW IN STOCK
Turbine Wheel	442029-0003 (8925743, 2950012372943)(Ind. 96.52 mm, Exd. 83.97 mm, 11 Blades) $524.80 NEW IN STOCK
Comp. Wheel	443120-0001 (Ind. 70.9 mm, Exd. 102.3 mm,Trm 48*54, 7+7 Blades)(23501285) $290.81 NEW IN STOCK
Back plate	442027-0001 (8925746) $154.46 NEW IN STOCK
Heat shield Number	407657-0004 (9N2037, 9N3701, 8925757)(1101680340) $47.99 NEW IN STOCK
Repair Kit	468267-0000 (1101678752) $91.60 NEW IN STOCK
Turbine Housing	443110-0001 (23501281) $432.02
Turbine Housing AR	1.08
Gasket oil inlet	129119 (201049, 9737, 1S6595, 210019-0000, 409266-0003, 3819900)(1900000035) (Paper) $4.48
Gasket (oil outlet)	129120 (210018-0000, 409267-0002, 3709738, 3500682, 201048, 1S4810, 9988, 9738, 3519763)(1900000025) $4.38
Gasket (turbine inlet)	409038-0001 (409038-0000, 1S4295, 132040, 205396, 202873, 3500683, 1215736, 210017-0000, 210835-0000, 9749)(1900000003) $15.49

Application

Detroit Diesel Truck 6V92TAB, 6V92
